<p>The Castaly 52" Two-Side Planer w/Spiral Cutterhead PL-52-JS features a special Universal Joint Shaft Feed Roller Driver to ensure the feeding power.</p>
<h3>Features:</h3>
<div>
<ul>
<li>Special Universal Jointer Shaft Feed Roller Driver: to ensure the feeding power for the wet, rough limber and curve material for mass cutting power.</li>
<li>Standard with Heavy Duty Spiral Cutterhead for fast and smooth cutting.</li>
<li>Standard equip with Automatic Thickness Controller, easy and quick setting for the cutting thickness.</li>
<li>Upper & lower straight knife cutterheads for accurate and powerful two-sided planing in one pass.</li>
<li>Auto digital thickness control for quick and accurate setup.</li>
<li>The worktable surface was precision ground and then electric chrome-plated and polished to a smooth mirror finish. The durable wear resistance surface is easy to clean and maintain.</li>
<li>A heavy-duty feed conveyor with metal spikes firmly holds stock securely to the worktable and feeds positively giving a smooth finish for rough or final planing.</li>
<li>A step-less variable speed control for smooth adjustment of feed rate depending on the material hardness, depth of cut & width to provide the best finish surface and fast cutting performance.</li>
<li>The infeed conveyor is fitted with numerous pressure pins so the feeding process can be firmly stabilized. It will moderately press the stock, and then accurate planing surface can be performed to prevent jumping during processing of narrow or bent material.</li>
<li>A twist torsion anti-kickback device provides additional safety. It’s designed to work in conjunction with the built-in conveyor stop. It safeguards mechanical parts in case of overload.</li>
<li>The heavy-duty rigid cast iron frame supports the worktable and helps dampen vibration and ensures years of dependable service.</li>
<li>Powerful industrial motor for maximum cutting capacity.</li>
<li>All precision sealed long-life bearing for durability usage.</li>
<li>A swivel stand is designed for convenient knife changing on the bottom cutterhead.</li>
<li>Changing the knife on the upper cutterhead only requires removal of the upper dust chute.</li>
<li>The optional spiral insert heads design allows for fast, accurate insert changes and minimum down time.</li>
<li>Setup time is minimized to set cutterhead height using the auto material thickness device.</li>
<li>The top and bottom cutterheads are precision balanced to provide consistently smooth chatterfree planing regardless of the feed rate or hardness of material being planed.</li>
<li>A powerful ½ HP motor is utilized to quickly & conveniently make adjustments in thickness when setting the upper cutterhead.</li>
</ul>
<p> </p>
<table border="1" cellspacing="0" cellpadding="0">
<tbody>
<tr>
<td valign="top" width="276">
<p><strong>Specifications:</strong></p>
</td>
<td valign="top" width="240">
<p align="center"> </p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Table Area</p>
</td>
<td valign="top" width="240">
<p align="center">1350 x 2600 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Cutterhead Diameter</p>
</td>
<td valign="top" width="240">
<p align="center">156 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Cutting Circle</p>
</td>
<td valign="top" width="240">
<p align="center">158 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Max. Cutterhead Speed</p>
</td>
<td valign="top" width="240">
<p align="center">4000 RPM</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Infeed Roller Diameter</p>
</td>
<td valign="top" width="240">
<p align="center">140 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Outfeed Roller Diameter</p>
</td>
<td valign="top" width="240">
<p align="center">140 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Table Roller Diameter</p>
</td>
<td valign="top" width="240">
<p align="center">140 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Feed Rate</p>
</td>
<td valign="top" width="240">
<p align="center">4-16 m/min</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Max. Depth of Cut (Single Side)</p>
</td>
<td valign="top" width="240">
<p align="center">12 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Range of Wood Thickness</p>
</td>
<td valign="top" width="240">
<p align="center">50-250 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Widest Planeable Butted Stock</p>
</td>
<td valign="top" width="240">
<p align="center">1320 mm / 635 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Shortest Planeable Stock not Butted</p>
</td>
<td valign="top" width="240">
<p align="center">600 mm</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Motors</p>
</td>
<td valign="top" width="240">
<p align="center">40 HP (top) / 30 HP (bottom)</p>
</td>
</tr>
<tr>
<td valign="top" width="276">
<p>Machine Weight (Approx.)</p>
</td>
<td valign="top" width="240">
<p align="center">8000 kgs</p>
</td>
</tr>
</tbody>
</table>
</div>
