Castaly Auto Copy Lathe CL-1006
Have one to sell?
ConditionNew
New
Castaly Auto Copy Lathe CL-1006 includes variable cutting speed controls and uses hydraulic power to get best driving and cutting force.
Features:
Use the template to make easy duplicate copy performance.
Specially designed for processing wood under the length of 39-1/2" and diameter of 8-1/4".
Runs automatic continual cycles from feeding to finish.
Variable cutting speed controls and uses hydraulic power to get best driving and cutting force.
Performs exact positioning setting for wood materials and operates very efficiently.
Besides the two rough cutters, the machine also coordinates with profile-typed blades for the fine finish shape cutting.
The centralized control panel provides convenient operation of the machine.
Industrial full power motor for maximum cutting capacity.
Precision sealed long-life bearing.
Heavy cast iron frames and table for durability usage.
SPECIFICATIONS:
Max. Working Length
6 3/8" ~ 39 1/2"
Max. Working Diameter
1 1/8" ~ 8 1/4"
Turning Motor
10 HP x 2
Hydraulic Motor
3 HP x 1
Cutting Circle
2 ~ 12 Times/ Min.
Main Spindle Speed
2000 ~ 6000 RPM (var)
Electrical Control Style
By AC 220V Relay Control
Machine Dimensions
120" x 47" x 110"
N.W.
6240 LBS
G.W.
6900 LBS
