<p>Castaly offers several selections of Resaws. Refer to features and specifications of each to find the machine to best meet your requirements.</p>
<h3>Features:</h3>
<ul class="dotted-list">
<li class="simple-check-list">Machine was built with rugged construction throughout for maximum stability, high precision cutting and minimum trouble.</li>
<li class="simple-check-list">It is equipped with a digital controller for convenient and accurate thickness setting.</li>
<li class="simple-check-list">The feed conveyor has a tilting design allowing for maximum 30-degree bevel cuts.</li>
<li class="simple-check-list">When the feed conveyor is tilted for bevel cutting, a side support is applied for safe and stable cutting operations.</li>
<li class="simple-check-list">Variable feed speed is controlled by a frequency inverter for best cutting requested.</li>
<li class="simple-check-list">The infeed and outfeed pressure rollers are easily raised or lowered by a gear rack.</li>
<li class="simple-check-list">The infeed and outfeed pressure rollers are spring-loaded and easily adjusted for the horizontal or vertical direction to suit various workpiece thicknesses.</li>
<li class="simple-check-list">Blade tension is adjusted by means of a hand wheel.</li>
<li class="simple-check-list">A tension scale allows the operator to correctly adjust the tension for different blade thicknesses.</li>
<li class="simple-check-list">The cast iron saw blade wheel is dynamically balanced for smooth running.</li>
<li class="simple-check-list">Blade guard is easily lifted up, supported by two nitrogen gas cylinders for convenient blade change.</li>
<li class="simple-check-list">The roller type return conveyor equipped at left side of the machine provides easy repetitive cutting.</li>
</ul>
<p> </p>
<table>
<tbody>
<tr>
<td>
<p><strong>Specifications:</strong></p>
</td>
<td style="text-align: center;"> </td>
</tr>
<tr>
<td>
<p>Max. Working Sizes (W x H)</p>
</td>
<td style="text-align: center;">
<p>24" x 10"</p>
</td>
</tr>
<tr>
<td>
<p>Distance from Blade to Conveyor Table</p>
</td>
<td style="text-align: center;">
<p>5/32" to 10" (4 mm to 250 mm)</p>
</td>
</tr>
<tr>
<td>
<p>Conveyor Belt Size</p>
</td>
<td style="text-align: center;">
<p>585 x 760 mm</p>
</td>
</tr>
<tr>
<td>
<p>Saw Wheel Diameter</p>
</td>
<td style="text-align: center;">
<p>Ø28" x 2" (W)</p>
</td>
</tr>
<tr>
<td>
<p>Feed Speed</p>
</td>
<td style="text-align: center;">
<p>5 to 25 m/min</p>
</td>
</tr>
<tr>
<td>
<p>Saw Blade Size (L x W x T)</p>
</td>
<td style="text-align: center;">
<p>4966 x 54 x 1.0 mm</p>
</td>
</tr>
<tr>
<td>
<p>Saw Wheel Motor</p>
</td>
<td style="text-align: center;">
<p>30 HP</p>
</td>
</tr>
<tr>
<td>
<p>Hydraulic System Motor</p>
</td>
<td style="text-align: center;">
<p>Infeed: OMP250 / Outfeed: OMP160</p>
</td>
</tr>
<tr>
<td>
<p>Gear box Motor</p>
</td>
<td style="text-align: center;">
<p>1/4 HP x 6P</p>
</td>
</tr>
<tr>
<td>
<p>Hydraulic System Motor</p>
</td>
<td style="text-align: center;">
<p>60 kg/ cm<sup>2</sup></p>
</td>
</tr>
<tr>
<td>
<p>Dust Hood Diameter</p>
</td>
<td style="text-align: center;">
<p>Ø4" x 2</p>
</td>
</tr>
<tr>
<td>
<p>N. W.</p>
</td>
<td style="text-align: center;">
<p>1900 kg</p>
</td>
</tr>
<tr>
<td>
<p>Packing Dimensions</p>
</td>
<td style="text-align: center;">
<p>3090 x 2260 x 2050 mm</p>
</td>
</tr>
<tr>
<td>
<p>Optional</p>
</td>
<td style="text-align: center;">
<p>Inverter</p>
</td>
</tr>
</tbody>
</table>
