Castaly 1 1/4" Super Duty Shaper (Extra Long Table) SP-833L
Have one to sell?
ConditionNew
New
Castaly 1 1/4" Super Duty Shaper (Extra Long Table) SP-833L features an extra long table measuring 88" x 39".
Features:
Designed for heavy industrial work.
Industrial full power motor for maximum cutting capacity.
Precision ground large cast iron table with slide extension support table.
Four spindle speeds for versatile cutting.
Industrial full power motor for heavy cutting capacity.
Sealed long-life ball bearing.
Heavy sheet metal cabinet base for durability usage.
Magnetic control for overload protection.
Quick-change spindles.
Individual two side micro adjustable fence.
Spring hold-downs.
Emergency Stop Foot Brake (SP-883L only).
Spindle Lock by foot pedal for quick change (SP-883L only).
SPECIFICATIONS:
Table Size
88" x 39"
Height of Work Table
33 1/2"
Spindle Dimensions:
Diameter (Standard)
1 1/4"
External Length
6 1/2"
Stroke
7"
Max. Height Above Table
6 1/4"
Max. Lower Under Table
1 3/4"
Speed (RPM)
3000/ 4500/ 7000/ 10000
Motor
10 HP, 3 PH
Locking of Spindle
by Foot Pedal
N.W.
1750 LBS
G.W.
1940 LBS
